Creality SPARKX i7 Color Combo 3D打印机 CFS Lite多色料盒组合套装

以下技术资料为英文原文。

Specifications

Printing Performance

Printing Technology: Fused Filament Fabrication (FFF)

Build Volume: 260 x 260 x 255 mm

Max Printing Speed: <= 500 mm/s

Max Acceleration: <= 10000 mm/s2

Printing Accuracy: 100 +/- 0.1 mm

Layer Thickness: 0.05 - 0.3 mm

Filament Compatibility: PLA, PETG, PLA-CF, TPU (Shore hardness 64D or higher)

Extruder and Build Platform

Extruder Type: Direct drive

Max Nozzle Temperature: <= 300 C

Max Heated Bed Temperature: <= 100 C

Nozzle Diameter: 0.4 mm standard (compatible with 0.2 / 0.6 / 0.8 mm)

Quick-Release Nozzle: Supported, tool-free

Build Plate: Double-sided gold-textured PEI plate

Levelling: Fully automatic

Smart Features and Electronics

Operating System / Firmware: Creality OS

Auxiliary Functions: Input Shaping, Pressure Advance

AI Camera: 720p with fill light

Smart Monitoring: Spaghetti detection, air-printing detection, clog and tangle detection, filament run-out detection

Special Monitoring: Cutter wear monitoring, build plate detection

Failure Handling: Resume after power loss, resume after filament break

Slicing Software: Creality Print 6.3 or later

File Storage: 8 GB eMMC

Physical and Electrical Specifications

Display: 2.85-inch colour touchscreen

Machine Dimensions: 470 x 423 x 456 mm

Net Weight: 9.12 kg

Input Voltage: AC 100-240V~ 50/60 Hz

Rated Power: 700W at 220V / 400W at 110V

Connectivity: Wi-Fi (2.4 GHz), USB flash drive, RS 485 (6-pin)

Print Status Light: RGB multicolour

Interface Languages: Chinese / English / German / Spanish / French / Italian / Portuguese / Russian / Turkish / Japanese / Korean / Arabic

CFS Lite Multicolour Filament System

An automatic 4-colour changer unit, comparable to the Bambu Lab AMS Lite.

Compatible Machines: SPARKX i7 (more models to be supported)

Number of Spools: 4, supports multicolour printing

Product Dimensions: 362 x 227 x 364 mm

Net Weight: 3.42 kg

Power Supply: 24V DC, supplied by the printer over the RS 485 cable

Rated Power: 10W

Communication Protocol: RS 485, CAN 2.0

Drying Method: Desiccant

Smart Features: Automatic filament identification (RFID), automatic reload, tangle and run-out detection

Spool Compatibility: 1 kg spools, 195-202 mm diameter, 42-68 mm thickness

Multi-Unit Serial Connection: Not supported
